Additional program memory possible:
No
Appendant operation agent (Ex ia):
No
Appendant operation agent (Ex ib):
No
Category according to EN 954-1:
B
ETIM Class:
PLC CPU-module
Explosion safety category for dust:
None
Explosion safety category for gas:
None
Front build in possible:
No
Max. number of time switches:
255
Number of analogue inputs:
0
Number of analogue outputs:
0
Number of digital inputs:
36
Number of digital outputs:
24
Number of HW-interfaces industrial Ethernet:
0
Number of HW-interfaces other:
0
Number of HW-interfaces parallel:
0
Number of HW-interfaces RS-232:
0
Number of HW-interfaces RS-422:
0
Number of HW-interfaces RS-485:
0
Number of HW-interfaces USB:
1
Number of HW-interfaces Wireless:
0
Number of interfaces PROFINET:
0
Number of relay outputs:
24
Performance level acc. EN ISO 13849-1:
Level a
Processing time (1K, binary operation):
1.1ms
Rack-assembly possible:
No
Radio standard Bluetooth:
No
Radio standard WLAN 802.11:
No
Rail mounting possible:
Yes
SIL according to IEC 61508:
None
Suitable for safety functions:
No
Supply voltage AC 50 Hz:
85 - 264V
Supply voltage AC 60 Hz:
85 - 264V
Supporting protocol for ASI:
No
Supporting protocol for AS-Interface Safety at Work:
No
Supporting protocol for CAN:
No
Supporting protocol for Data-Highway:
No
Supporting protocol for DeviceNet:
No
Supporting protocol for DeviceNet Safety:
No
Supporting protocol for EtherNet/IP:
No
Supporting protocol for Foundation Fieldbus:
No
Supporting protocol for INTERBUS:
No
Supporting protocol for INTERBUS-Safety:
No
Supporting protocol for KNX:
No
Supporting protocol for LON:
No
Supporting protocol for MODBUS:
No
Supporting protocol for other bus systems:
No
Supporting protocol for PROFIBUS:
No
Supporting protocol for PROFINET CBA:
No
Supporting protocol for PROFINET IO:
No
Supporting protocol for PROFIsafe:
No
Supporting protocol for SafetyBUS p:
No
Supporting protocol for SERCOS:
No
Supporting protocol for SUCONET:
No
Supporting protocol for TCP/IP:
No
Voltage type of supply voltage:
AC
Wall mounting/direct mounting:
Yes
With optical interface:
No
