GS2110-WTBD-N Mitsubishi HMI New Multi Drop Connection Unit

Ask Lasest Price
Brand Name :	Mitsubishi
Model Number :	GS2110-WTBD-N
Price :	$120-$800
Payment Terms :	T/T, western union
Supply Ability :	10pc/per week

Add to Cart

Product Details
Company Profile

GS2110-WTBD-N Mitsubishi HMI New Multi Drop Connection Unit

GS2110-WTBD-N Mitsubishi HMI New Multi-Drop Connection Unit

Basic information

Model name	GS2110-WTBD-N
Overview	10” Wide, WVGA, TFT color LCD 65536 colors, Panel color: Black, Power supply voltage: 24 V DC
Conformance standard	UL cUL CE(EMC) CE(RoHS) KC

GOT SIMPLE Series

Simple, high functioning, and user friendly model for a reliable system.

GOT SIMPLE collects the data from multiple devices!
GOT SIMPLE manages the data of all connected industrial devices. The data can be collected at an arbitrary timing and can be used for data analysis and feedback.

Use GOT SIMPLE to control industrial devices!

[Multi-channel function]
Up to 2 industrial devices can be controlled with one GOT SIMPLE. The data can be easily transferred between devices with just simple settings in GT Works3.

Sequence programs and parameters can easily be modified at the worksite

[FA transparent function]
The GOT SIMPLE acts as a transparent gateway to enable programming, start up, and adjustment of Mitsubishi Electric industrial devices. Users do not have to bother with changing cable connections.

Basic specifications

Model

Product name

Series name

Model name

GS2110-WTBD-N

GS21 model

GOT SIMPLE

GS21

Performance specifications

Display section^*1	Display device
	Screen size
	Resolution
	Display size
	Number of displayed characters
	Display color
	Brightness adjustment
	Backlight
	Backlight color
Touch panel^*2	Type
	Key size
	Simultaneous press
	Life
Panel color
Human sensor	Detection length
	Detection temperature
Memory	Flash memory	Capacity
		Life (number of write times)
		Application
Built-in interface	RS-232 interface	Number of channel
		Transmission speed
		Connector shape
	RS-422/485 interface	Number of channel
		Transmission speed
		Connector shape
		Terminating resistor
	RS-422/232 interface	Number of channel
		Transmission speed
		Connector shape
	RS-422 interface	Number of channel
		Transmission speed
		Connector shape
		Terminating resistor
	Ethernet interface	Number of channel
		Transmission speed
		Connector shape
	Bus interface	Type
		Number of channel
	RGB interface
	Printer interface
	USB interface (host)	Number of channel
		Maximum transfer rate
		Connector shape
	USB interface (device)	Number of channel
		Maximum transfer rate
		Connector shape
	SD memory card interface
	CF card interface
	PC card interface
	Option function board interface
	Memory board interface
Buzzer output
LED specifications	POWER LED
Installation method
Protective structure^*3
External dimensions
Panel cut dimensions
Weight (excluding a fitting)

TFT color LCD

WVGA: 800 x 480 dots

222 (W) x 132.5 (H) mm
(8.74 (W) x 5.22 (H) inch)
(Horizontal format)

16-dot standard font: 50 characters x 30 lines (two-byte characters)
12-dot standard font: 66 characters x 40 lines (two-byte characters)
(Horizontal format)

65536 colors

32 levels

LED (not replaceable)

White

Analog resistive film

Minimum 2 x 2 dots (per key)

Not available (Only 1 point can be touched.)

1 million touches or more (operating force: 0.98 N or less)

Black

－

Flash memory (Internal) : 15 MB

100000 times

for storing project data, OS

1 channel

115200, 57600, 38400, 19200, 9600, 4800 bps

D-sub 9-pin (male)

1 channel

115200, 57600, 38400, 19200, 9600, 4800 bps

D-sub 9-pin (female)

330 Ω, 110 Ω, OPEN (Selectable by the terminating resistor setting switch.)

－

1 channel

100BASE-TX, 10BASE-T

RJ45 (modular jack) AUTO MDI/MDI-X

－

1 channel (rear face)

Full-Speed 12 Mbps

USB Mini-B

1 channel, SDHC compliant (maximum 32 GB)

－

Single tone (LONG/SHORT/OFF adjustable)

－

Standard

Front: IP65F

272 (W) x 214 (H) x 56 (D) mm
(10.71 (W) x 8.43 (H) x 2.21 (D) inch)

258 (W) x 200 (H) mm
(10.16 (W) x 7.88 (H) inch)

1.3 kg

(*1)Bright dots (always lit) and dark dots (unlit) may appear on a liquid crystal display panel. It is impossible to completely avoid this symptom, as the liquid crystal display comprises of a great number of display elements. Flickers and partial discoloration may be generated on the liquid crystal display panel due to individual differences of panels. Please note that these phenomena appear due to its characteristic and are not caused by product defect.

(*2)The touch panel is an analog-resistive type. Simultaneous pressing of two or more areas on the touch panel may activate the switch between those areas. Do not press two or more areas simultaneously on the touch panel.

(*3)Note that this does not guarantee all users' operation environment. In addition, the product may not be used in environments under exposition of oil or chemicals for a long period of time, or in environments filled with oil-mist.
