    GT2712-STBA GOT2000 SERIES Advanced Operation Programmable Terminal

    Ask Lasest Price
    Brand Name : Mitsubishi
    Model Number : GT2712-STBA
    Price : $120-$800
    Payment Terms : T/T, western union
    Supply Ability : 10pc/per week
    • Product Details
    • Company Profile

    GT2712-STBA GOT2000 SERIES Advanced Operation Programmable Terminal

    GT2712-STBA GOT2000 SERIES Advanced Operation Programmable Terminal


    Basic information

    Product main image

    Model nameGT2712-STBA
    Overview12.1”, SVGA, TFT color LCD 65536 colors, Panel color: Black, Power supply voltage: 100 V AC to 240 V AC
    Conformance standardUL cUL CE(EMC) CE(LVD) CE(RoHS) KC LR NK DNV ABS RINA BV

    Advanced model with multi-touch gesture functions

    Zoom in to easily operate small and hard to reach switches.
    After zooming in, scroll the display to show the area you want to operate.
    Prevent accidental operations by designating two pressing points for critical operations.

    A wide variety of specifications suit every system design

    Communication interfaces such as Ethernet, RS-232, RS-422/485, USB host/device and SD memory card are standard features. High capacity data processing ensure smooth screen operation even when multiple tasks, such as logging, script, alarm, or device data transfer, are running.
    In addition, image recording, image playback, video image input, and RGB output are available, thus all the functions of GOT2000 can be used on GT27 models.

    With Backup/Restoration function, fear troubles no more!

    The programs and parameters of the programmable controller CPU can be backed up to the SD memory card or USB memory device in the GOT. In case of a CPU failure, users can perform batch operation to restore the data to the controller.

    HUMAN MACHINE INTERFACE
    SERIESGOT2000 SERIES
    TYPEGT27 MODEL
    POWER SUPPLY (V)100-240
    CURRENT TYPEAC
    DISPLAYTFT
    DISPLAY COLOUR65536
    DISPLAY SIZE (INCH)12,1
    RESOLUTION (PIXELS)800X600
    INTERNAL MEMORY CAPACITY (MB)256
    MEMORY CARD SLOTSD
    USB3
    ETHERNET PORT1
    RS-2321
    RS-422/4851
    NETWORK OPTIONSMODBUS,CCLINK,M'NET,ETH,BUS
    SLOT FOR OPTIONAL CARDSYES
    PROTECTION CLASSIP67F

    PRODUCT DIMENSIONS & WEIGHT

    WIDTH (MM)316
    HEIGHT (MM)246
    DEPTH (MM)52
    WEIGHT (KG)2,4
